ZLY-200
Zhichu
1.Triple-eccentric drive is precisely counterbalanced to impart smooth,uniform motion to all flasks regardless of their position on the platform.
2.Streamlined shape with electro-static coating surface and high anti-corrosion property.
3.The platform and clamps made from stainless steel have corrosion resistance and oxidation-resistance properties that easy to take out and cleaning.
1.Triple-eccentric drive is precisely counterbalanced to impart smooth,uniform motion to all flasks regardless of their position on the platform.
2.Streamlined shape with electro-static coating surface and high anti-corrosion property.
3.The platform and clamps made from stainless steel have corrosion resistance and oxidation-resistance properties that easy to take out and cleaning.
1.Servo-motor makes speed control precisely and ensures high-speed performance and stability.
2.LCD Touch Screen that making parameters setting and viewing easily. Such as:
a.The setting speed, time and the real speed, remaining time are shown simultaneously.
b. Keyboard blocking prohibits miss operation.
c.Setting rotation direction is positive or reverse.
3.Data memory function can check the history record within 3 months.
4.The plastic molding clamps make it easily to put and take flasks with one hand.
1.Servo-motor makes speed control precisely and ensures high-speed performance and stability.
2.LCD Touch Screen that making parameters setting and viewing easily. Such as:
a.The setting speed, time and the real speed, remaining time are shown simultaneously.
b. Keyboard blocking prohibits miss operation.
c.Setting rotation direction is positive or reverse.
3.Data memory function can check the history record within 3 months.
4.The plastic molding clamps make it easily to put and take flasks with one hand.
Product Name | |
Model | ZLY-200 |
Shaking Range | 10-300rpm |
Shaking Control | ±1rpm |
Orbit (diameter) | φ26mm(φ50mm ) |
Display | LCD(Touch Screen) |
Max. Capacity (Stainless steel clamps) | 250ml×66 or 500ml×45 or 1000ml×28 or 2000ml×15 or 5000ml×11 |
Max. Capacity (Plastic cement clamps) | 250ml×66 or 500ml×45 or 1000ml×28 or 2000ml×15 or 3000ml×15 |
Timing Range | 0-999.9hrs |
Platform Size(L×W) | 1003mm×592mm |
Standard Platform | 500ml×45 (optional in other sizes clamps) |
Power Source | AC220±10% 50~60Hz |
Overall Dimensions (L×W×H) | 1003mm×670mm×300mm |
Weight | 148kg |
Noise Level | <55dB |
Product Name | |
Model | ZLY-200 |
Shaking Range | 10-300rpm |
Shaking Control | ±1rpm |
Orbit (diameter) | φ26mm(φ50mm ) |
Display | LCD(Touch Screen) |
Max. Capacity (Stainless steel clamps) | 250ml×66 or 500ml×45 or 1000ml×28 or 2000ml×15 or 5000ml×11 |
Max. Capacity (Plastic cement clamps) | 250ml×66 or 500ml×45 or 1000ml×28 or 2000ml×15 or 3000ml×15 |
Timing Range | 0-999.9hrs |
Platform Size(L×W) | 1003mm×592mm |
Standard Platform | 500ml×45 (optional in other sizes clamps) |
Power Source | AC220±10% 50~60Hz |
Overall Dimensions (L×W×H) | 1003mm×670mm×300mm |
Weight | 148kg |
Noise Level | <55dB |
