VIEW
The stainless steel frames with heating function around door class can adjust the temperature as user's need.
Insulating and tempered door glass as well as the stainless steel frames with heating function avoid condensation effectively, also provides good view of culture state without opening door.
Touch Screen that making parameters setting and viewing easily. Such as:
1. The setting temperature, speed, time and the real temperature, speed, remaining time are shown simultaneously.
2. Setting rotation direction is positive or reverse.
For those utilizing a stackable CO₂ incubator, these features are essential for maintaining optimal culture conditions while maximizing space efficiency. The clear view provided by the heated door glass and the intuitive touch screen interface ensure precise monitoring and control, enhancing the reliability and quality of experimental outcomes.
SENSOR
Infrared CO2 sensor measures the CO2 concentration automatically with high sensitivity.
For each shaker, a bottle of CO2 gas (20kg) can be used not less than 35days if the door is open normally, and about 145 days when door is not opened.
PT-100 temperature sensor
Humidity sensor(option)
DATA RECORD
Data memory, can record more than 600,000,00.00 datas.
Data curves such as real-time temperature and speed can be displayed.
Data easily transfer through the USB interface.
RS-232 or RS-485 interface is optional.
OTHER FEATURES
Embedded blackout curtain stretching repeatedly and not easy to damage, completely avoids light influence on culture(option).
With water pan for natural humidification. High temperature steam automatic humidity control system, ranging from ambient humidity to 90%(option).
Compliant with FDA 21CFR part 11 computerized software system(option)
Photosynthesis Lighting System(option)
Mobile and PC remote monitor(option)
